Three small surprises in Chevrolet pickup option sheets
A spare tire could be base equipment and still need its own order entry. A heavy-duty battery could have the same description on two pickup sheets but different package wording. And a radiator option could carry a transmission restriction that applied to only part of the list. Three Chevrolet examples show what those details actually said, without combining different years into an imaginary truck.
1975 K10: base equipment, separately ordered
Chevrolet’s 1975 K10 regular-cab tire chart, dated September 16, 1974, separates front and rear selections into Highway and On-Off Road columns. For the L78-15/B entries, LB appears under Highway and LC under On-Off Road on both sides of the chart. The distinction is not another tire size: the description stays L78-15/B while the column and code change. [1]
The revealing detail is below the rows. A note identifies the marked LB entries as the base tire on eight-cylinder models. It also identifies the L78-15/B Highway Blackwall spare, code LB, as base equipment on those models, but says it must be ordered separately unless an optional spare is specified. Above the K10 rows, a separate instruction calls for a spare matching either the front or rear tires. [1]
So “base equipment” did not make the spare-tire instruction disappear. The sheet distinguishes the equipment description from the act of specifying it. Its eight-cylinder base-tire note belongs to the marked LB entries, not automatically to LC or every other choice in the chart. This is the 1975 regular-cab K10 table, not a tire rule for every Chevrolet pickup.
1976 C10 and K10: the battery note moves
The C10 and K10 pickup order sheets revised March 26, 1976 both describe UA1 as a heavy-duty 4,000-watt Delco Freedom battery, with separate lines for applications with and without a V8 engine. Yet their package-inclusion language is arranged differently. [2]
On the C10 sheet, the shared UA1 description says it is included with Z56 Cold-Climate. The V8 line adds inclusion with Z82 Trailering or the LF8 engine. That additional wording sits on the V8 line, not on the line without a V8.
On the K10 sheet, inclusion with Z82 Trailering or Z56 Cold-Climate appears in the shared UA1 description above both engine lines. There is no corresponding LF8 clause on its V8 line. These are two different printed arrangements, not a reason to copy the C10 clause into the K10 listing. TP2, the auxiliary battery, is a separate entry; the UA1 inclusion language does not describe it. [2]
The interesting difference here is not a new battery rating. It is where Chevrolet placed the inclusion conditions. The sheets establish that wording, not the battery originally installed in any particular surviving truck.
1978 pickups: a radiator exclusion with a boundary
Chevrolet’s pickup option sheet published March 10, 1978 lists V01 under heavy-duty radiator. Its common instruction excludes that option when C60 air conditioning or the LF4 400-4 BBL engine is specified. [3]
The application lines then separate C10/K10 engine combinations from C20–30 and K20–30 applications. Between those groups, an instruction specifically for C/K20–30 says the option is unavailable with MX1 automatic transmission. That restriction does not extend to the preceding C10/K10 rows. For example, the C10/K10 line naming LS9 350-4 BBL remains under the common air-conditioning and LF4 condition, not the C/K20–30-only MX1 condition. [3]
This describes the separately listed V01 option. It does not establish what radiator was supplied with an excluded combination. Like the spare and battery examples, it answers a precise historical ordering question, not a present-day replacement question. Tire suitability, battery replacement and cooling-system service require other evidence.
Sources
[1] Chevrolet Motor Division, Chevrolet Trucks 1975, Pickup—Page 24 / PDF page 35, “Front and Rear Tire Availability Chart,” K10 Series Regular Cab, September 16, 1974; LB/LC rows, shared spare instruction and LB footnote. Original Chevrolet information kit.
[2] 1976 Dealer Order Guide, Chevrolet Pickup section, C10 Pickup Page 5 / PDF 5 and K10 Pickup Page 33 / PDF 33, both revised March 26, 1976, “Batteries: 12-volt.” Preserved original scan; no verified public scan URL is available. These citations describe pickup ordering, not the separate Suburban schedule.
[3] Chevrolet Motor Division, Chevrolet Trucks 1978, Pickup—Page 32 / PDF page 35, “Options and Accessories When Installed by Chevrolet,” heavy-duty radiator/V01 group, published March 10, 1978. Original Chevrolet information kit. The page’s March 1, 1978 statement concerns price applicability, not an established equipment-change date.
